| 01. FRAME | ONE-SIXTY LITE III; 171 STR mullet / 162 STR 29"; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| 02. SIZES | XShort-Short-Mid-Long-XLong |
| 03. FORK | Marzocchi Z1; Air; 170 STR; Tapered; 44mm fork offset; 29x2.6" max. WHS |
| 04. SHOCK | Fox Float X Performance; platform |
| 05. GEARS | 1 x 12 |
| 06. CRANKSET | Race Face Aeffect; 32 ATC |
| 07. CRANK LENGTH | 170 mm-S up |
| 08. BOTTOM BRACKET | Race Face BSA 68/73 - 24mm |
| 09. CASSETTE | Shimano Deore M6100; 10-51 ATC; 12 GER |
| 10. CHAIN | KMC X12 |
| 11. REAR DERAILLEUR | Shimano SLX M7100 Shadow+; SGS |
| 12. SHIFTER - FRONT | n/a |
| 13. SHIFTER - REAR | Shimano XT; Multi Release |
| 14. DROPPER LEVER | Shimano SL -MT500-IL |
| 15. BRAKE - FRONT | Shimano SLX M7120; 4 piston |
| 16. BRAKE - REAR | Shimano SLX M7120; 4 piston |
| 17. ROTOR - FRONT | Shimano RT64; 203 mm |
| 18. ROTOR - REAR | Shimano RT64; 203 mm |
| 19. HANDLEBAR | MERIDA TEAM TR; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
| 20. STEM | MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| 21. STEM SIZE | 40 mm all sizes |
| 22. HEAD SET | MERIDA-8151 1-1/8"-1.5" cartridge bearing set |
| 23. SEAT POST | MERIDA TEAM TR; 34.9 DSP; 0 SSB; all sizes 30-230 SPT |
| 24. SADDLE | MERIDA EXPERT SL; V-mount; incl. MERIDA minitool |
| 25. SPOKES | Double Butted Black stainless |
| 26. HUB - FRONT | Shimano SLX; 110x15 WHF; 32 SPH; Centerlock |
| 27. HUB - REAR | Shimano SLX; 148x12 WHR, 32 SPH; Centerlock |
| 28. AXLE - REAR | MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
| 29. RIMS | MERIDA EXPERT TR; 29 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); rear 27.5" up to Size M / L & XL rear 29" |
| 30. TYRE - FRONT | Maxxis Assegai; 29x2.5"; fold; TR EXO+ 3C MaxxGrip |
| 31. TYRE - REAR | Maxxis DHR; 27.5x2.4" XS/S/M 29x2.4" L/XL; fold; TR DD 3C MaxxTerra |
| 32. BOTTLE CAGE | - |
| 33. FENDER | - |
| 34. E-SHIFT PARTS | - |
| 35. OTHER | MERIDA Multitool with saddlebox |
| 36. MAX RIDER WEIGHT | 135kg |
