| FRAME | eBIG.NINE LITE III; MAT aluminium; 29x2.35" without fender max./ 29"x2.25" with fender max. WHS; 148x12 AST; intube |
| SHOCK | |
| FORK | Suntour XCM34-Boost LOR DS; 100mm; Tapered; 51mm fork offset; 29x2.4" max WHS |
| BRAKE - FRONT | Shimano MT-200; 2 piston |
| BRAKE - REAR | Shimano MT-200; 2 piston |
| ROTOR - FRONT | Shimano RT30; 180 mm |
| ROTOR - REAR | Shimano RTEM300; 180 mm |
| CHAIN | Shimano LG500 |
| CHAINWHEEL | Shimano CRE70-B; 34 ATC |
| CRANK/SIZE | Shimano FC-EM600; 165 mm for all sizes |
| BB SET | included |
| DERA - FRONT | |
| DERA - REAR | Shimano CUES U6000; GS |
| FREEWHEEL | Shimano LG300; 11-48 ATC; 10 GER |
| PEDAL | VP VPE-537 |
| GRIP | MERIDA EXPERT TK |
| H-BAR | MERIDA EXPERT CC; MAT aluminium; 720 WHB; 10 RHB |
| H-B STEM | MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable |
| STEM/SIZE | 90 mm all sizes |
| HEAD SET | MERIDA-8155 (for the steerer 1-1/8"~1.5") |
| HUB - FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB - REAR | Shimano TC500-HM-B; 148x12 WHR; 36 SPH; Centerlock |
| AXLE - FRONT | |
| AXLE - REAR | MERIDA COMP TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA COMP CC II; 25 IWR; MAT aluminium |
| RIM TAPE | |
| SADDLE | MERIDA EXPERT TK; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB |
| SHIFTER - FRONT | |
| SHIFTER - REAR | Shimano CUES U6000-11 |
| INNER TUBE | Ultralite-29er |
| TYRE - FRONT | KENDA Booster; 29x2.2"; wire |
| TYRE - REAR | KENDA Booster; 29x2.2"; wire |
| BOTTLE CAGE | BOTTLE CAGE ADAPTER, BK-003 |
| CARRIER | MERIDA MA008-1 w/spring clamp + Spanninga GLOW XE |
| FENDER | Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
| KICKSTAND | CL-KA98, 29" |
| LIGHT - FRONT | LEZYNE E-BIKE HECTO STVZO E65 |
| LIGHT - REAR | Spanninga Commuter GLOW XE |
| FRAME LOCK | Abus 4650 L |
| DRIVE UNIT | Shimano EP6; 85Nm |
| DRIVE COVER | SM-DC-EP801 |
| BATTERY | Shimano EN806; 630Wh |
| BATTERY CHARGER | Shimano EC-E6002; 2A charging current |
| BATTERY LOCK | Abus key |
| DISPLAY | Shimano SC-EN500A |
| Frame Name | eBIG.NINE LITE III | eBIG.NINE LITE III | eBIG.NINE LITE III | eBIG.NINE LITE III |
| Frame Size Name | S | M | L | XL |
| Tyre Sizes | 29" | 29" | 29" | 29" |
| Frame Size Inch | ||||
| ST seat tube [mm] | 380 | 430 | 480 | 530 |
| Ste Seat Tubes Effective Mm | ||||
| STA seat tube actual [mm] | ||||
| TT top tube [mm] | 588 | 605 | 625 | 645 |
| CS chain stay length [mm] | 465 | 465 | 465 | 465 |
| HTA head tube angle [°] | 67.5 | 67.5 | 67.5 | 67.5 |
| STA seat tube angle [°] | 74.5 | 74.5 | 74.5 | 74.5 |
| Stae Seat Tube Angle Effective Deg | ||||
| Staa Seat Tube Angle Actual Deg | ||||
| BD bottom bracket drop [mm] | 62.5 | 62.5 | 62.5 | 62.5 |
| HT head tube [mm] | 115 | 120 | 130 | 140 |
| FL fork length [mm] | 527 | 527 | 527 | 527 |
| FO fork offset [mm] | ||||
| R reach [mm] | 411 | 427 | 445 | 462 |
| S stack [mm] | 636 | 640 | 650 | 659 |
| WB wheel base [mm] | 1165 | 1183 | 1204 | 1225 |
| SH stand over height [mm] | 719 | 750 | 794 | 835 |
