| FRAME | eONE-EIGHTY LITE; aluminium; 180mm travel; 27.5" x 2.6" max. wheelsize; 148x12mm axle standard |
| FRAME SIZE | XShort / Short / Mid / Long / XLong |
| FORK | Rock Shox Zeb Ultimate eMTB Air; 180mm; Tapered; 44mm offset; 29x2.6" max |
| REAR SHOCK | Rock Shox Vivid Ultimate; Platform |
| DRIVE UNIT | Bosch Performance Line CX |
| BATTERY | Bosch PowerTube 800 Wh |
| BATTERY CHARGER | Bosch 4A Charger (220-240V) |
| DISPLAY | Bosch Purion 400 |
| MODE SWITCH | Bosch Mini Remote |
| REAR DERAILLEUR | Shimano XT LG |
| SHIFTERS | Shimano XT |
| DROPPER POST LEVER | Shimano SL -MT500-IL |
| BRAKES | Shimano XT 4 piston |
| ROTORS | Shimano RT66, 220mm front, 203mm rear |
| CHAINRING | FSA 1x Alloy Spider + Mega Tooth steel chain ring; 36T |
| CRANK | FSA CK-220 wide E-Bike Forged Crankset; 165mm for all sizes |
| CHAIN | Shimano LG500 |
| CASSETTE | Shimano LG400; 11-50; 11 speed |
| PEDALS | VP VP-532 |
| HANDLEBAR | MERIDA EXPERT eTR; 780mm width; XS,S 20RHB; M,L,XL 30RHB |
| STEM | MERIDA EXPERT eTR II alum; 35mm dia; 0 angle; Supernova mount; 40 mm all sizes |
| HEADSET | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| SEATPOST | MERIDA TEAM TR II; 34.9mm; 0mm setback; S, M, L and XL 30-230mm, XS 30-200mm |
| SADDLE | Proxim Nembo Triox; V-mount adapter incl. MERIDA minitool |
| HUBS | DT Swiss HF 1700; 110x15mm, 148x12mm; 6-Bolt; Shimano HG |
| RIMS | DT Swiss HF 1700; 30mm inner; alum; Tubeless ready (tape and valves included) |
| REAR AXLE | MERIDA EXPERT TR including removeable lever, 6/4mm allen key |
| TYRE FRONT | Maxxis Assegai 29x2.5"; fold; TR EXO+ 3C MaxxGrip |
| TYRE REAR | Maxxis Minion DHR II, 27.5x2.4"; fold; 3C DD TR MaxxTerra |
| LIGHT FRONT | Lezyne Hecto StVZO E350+; Reverse MERIDA Custom Mount |
| LIGHT REAR | USB REAR Light CG-214RG |
| OTHER | Mr. Control CH-MDE-Mini chainguide |
