| FRAME | ONE-SIXTY LITE III; 171 STR mullet; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| SHOCK | DVO Jade X D3; coil; spring rate:XS, S:300 M:350 L:400 XL:450 |
| FORK | SR Suntour Durolux 38 RC; Air; 180 STR; Tapered; xxmm fork offset; 29x2.60" max. WHS |
| BRAKE - FRONT | Tektro Gemini HD-M535; 4 piston |
| BRAKE - REAR | Tektro Gemini HD-M535; 4 piston |
| ROTOR - FRONT | Tektro TR203-45; 203mm |
| ROTOR - REAR | Tektro TR203-45; 203mm |
| CHAIN | KMC xGlide |
| CHAINGUARD | MERIDA EXPERT TR ISCG05 |
| CHAINWHEEL | MERIDA Expert TR II; 32 ATC |
| CRANK/SIZE | 165 mm for all sizes |
| BB SET | Samox BSA 24mm EB2401 |
| DERAILLEUR - FRONT | |
| DERAILLEUR - REAR | Shimano CUES U6000; GS |
| FREEWHEEL | Shimano LG300; 11-48 ATC; 10 GER |
| PEDAL | |
| GRIP | MERIDA COMP EC |
| H-BAR | MERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
| H-B STEM | MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
| H-STEM/SIZE | 40 mm |
| HUB - FRONT | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB - REAR | Shimano TC500-HM-B; 148x12 WHR; 32 SPH; Centerlock |
| AXLE - REAR | MERIDA COMP TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA COMP TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5" |
| SADDLE | MERIDA COMP SL; 25% recycled material; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XSHORT/SHORT: 150 SPT - MID: 170 SPT - LONG: 200 SPT - XLONG: 230 SPT |
| SHIFTER - FRONT | Shimano SL-MT500-L |
| SHIFTER - REAR | Shimano CUES U6000 |
| TYRE - FRONT | Continental Kryptotal-F; 29x2.4"; fold; TR; Enduro casing; Soft Compund |
| TYRE - REAR | Continental Kryptotal-R; 27.5x2.4"; fold; TR; Enduro Casing; Soft Compound |
| BOTTLE CAGE | |
| E-SHIFT PARTS-1 | |
| OTHER 1 | Rear Brake Adapter PM 200mm to 203mm rotor |
| OTHER 2 | |
| OTHER 3 | |
| OTHER 4 | |
| OTHER 5 |
| Frame Name | ONE-SIXTY LITE III | ONE-SIXTY LITE III | ONE-SIXTY LITE III | ONE-SIXTY LITE III | ONE-SIXTY LITE III |
| Frame Size Name | XShort | Short | Mid | Long | XLong |
| Tyre Sizes | 29/27.5" | 29/27.5" | 29/27.5" | 29" | 29" |
| Frame Size Inch | |||||
| ST seat tube [mm] | 400 | 410 | 425 | 445 | 470 |
| Ste Seat Tubes Effective Mm | |||||
| STA seat tube actual [mm] | |||||
| TT top tube [mm] | 535 | 562 | 589 | 621 | 653 |
| CS chain stay length [mm] | 434 | 434 | 434 | 437.5 | 437.5 |
| HTA head tube angle [°] | 64 | 64 | 64 | 64 | 64 |
| STA seat tube angle [°] | 79 | 79 | 79 | 79 | 79 |
| Stae Seat Tube Angle Effective Deg | |||||
| Staa Seat Tube Angle Actual Deg | |||||
| BD bottom bracket drop [mm] | 7 | 7 | 7 | 27.5 | 27.5 |
| HT head tube [mm] | 95 | 95 | 95 | 105 | 120 |
| FL fork length [mm] | 581 | 581 | 581 | 581 | 581 |
| FO fork offset [mm] | |||||
| R reach [mm] | 415 | 442 | 470 | 498 | 525 |
| S stack [mm] | 615 | 615 | 615 | 625 | 638 |
| WB wheel base [mm] | 1188 | 1215 | 1242 | 1275 | 1308 |
| SH stand over height [mm] | 735 | 740 | 743 | 740 | 735 |
