| FRAME | SILEX LITE II; MAT aluminium; 700x47C max.WHS; 100x12/142x12 AST; BSA BBR |
| FORK | MERIDA SILEX CF2 II; Tapered; MAT carbon; 700x47C max. WHS |
| BRAKE LEVER | Shimano GRX400 |
| BRAKE - FRONT | Shimano GRX400; Hydraulic disc |
| BRAKE - REAR | Shimano GRX400; Hydraulic disc |
| ROTOR - FRONT | Shimano RT10; 180mm |
| ROTOR - REAR | Shimano RT10; 160mm |
| C-HOUSING | LEX40-L3 |
| CHAIN | KMC X10 |
| CHAINWHEEL | Shimano GRX600; 46-30 ATC |
| CRANK/SIZE | 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL |
| BB SET | Attached |
| DERAILLEUR - FRONT | Shimano GRX400 |
| DERAILLEUR - REAR | Shimano GRX400 |
| FREEWHEEL | Shimano CS-HG50; 11-36 ATC; 10 GER |
| PEDAL | |
| GRIP | MERIDA ROAD Expert |
| HANDLEBAR | MERIDA EXPERT GRII; MAT aluminium; 400mm (XS-S) , 420mm (M) , 440mm (L/XL) |
| H-B STEM | MERIDA TEAM CC III; MAT aluminium; 31.8 DSH; -6 ASD |
| H-STEM/SIZE | 80 mm all sizes |
| HUB - FRONT | Shimano HB-TC500; 100x12 WHF; 28 SPH; Centerlock |
| HUB - REAR | Shimano FH-TC500-HM; 12-142 WHR; 28 SPH; Centerlock |
| AXLE - FRONT | MERIDA EXPERT TR |
| AXLE - REAR | MERIDA EXPERT TR; including removable lever; 6/4mm allen key |
| RIM | MERIDA EXPERT SLII; 23 IWR; 25 HRI; MAT aluminium; Tubeless ready (tubeless |
| SADDLE | MERIDA COMP SL; 25% recycled material; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA COMP CC; MAT aluminium; 27.2 DSP; 5 SSB |
| SHIFTER - FRONT | Shimano GRX400 |
| SHIFTER - REAR | Shimano GRX400 |
| TYRE - FRONT | Maxxis Rambler; 700x45C; fold; TR; EXO |
| TYRE - REAR | Maxxis Rambler; 700x45C; fold; TR; EXO |
| E-SHIFT PARTS-2 | |
| E-SHIFT PARTS-3 | |
| OTHER 5 |
| Frame Name | SILEX LITE II | SILEX LITE II | SILEX LITE II | SILEX LITE II | SILEX LITE II |
| Frame Size Name | XS | S | M | L | XL |
| Tyre Sizes | 28" | 28" | 28" | 28" | 28" |
| Frame Size Inch | |||||
| ST seat tube [mm] | 460 | 490 | 520 | 550 | 580 |
| Ste Seat Tubes Effective Mm | |||||
| STA seat tube actual [mm] | |||||
| TT top tube [mm] | 550 | 565 | 580 | 600 | 620 |
| CS chain stay length [mm] | 430 | 430 | 430 | 430 | 430 |
| HTA head tube angle [°] | 69.5 | 69.5 | 69.5 | 69.5 | 69.5 |
| STA seat tube angle [°] | 74.5 | 74.5 | 74.5 | 74.5 | 74.5 |
| Stae Seat Tube Angle Effective Deg | |||||
| Staa Seat Tube Angle Actual Deg | |||||
| BD bottom bracket drop [mm] | 75 | 75 | 75 | 75 | 75 |
| HT head tube [mm] | 130 | 150 | 170 | 190 | 210 |
| FL fork length [mm] | 415 | 415 | 415 | 415 | 415 |
| FO fork offset [mm] | |||||
| R reach [mm] | 392 | 402 | 412 | 426 | 441 |
| S stack [mm] | 570 | 588 | 607 | 626 | 645 |
| WB wheel base [mm] | 1048 | 1065 | 1082 | 1104 | 1126 |
| SH stand over height [mm] | 744 | 771 | 798 | 825 | 852 |
