| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | STEP THROUGH ALLOY 6061 REMOVABLE BATTERY |
| FRAME STYLE | STEP-THROUGH |
| FORK MATERIAL | STEEL |
| FORK BRAND | UDING |
| FORK DESCRIPTION | COIL CAST ALLOY D5 WITH LOCKOUT |
| FRONT TRAVEL | UNDER 100MM |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO TOURNEY 7 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | LTWOO TRIGGER 7 SPEED |
| BRAKES | TEKTRO HD-M275 |
| BRAKE TYPE | HYDRAULIC DISC BRAKE |
| ROTOR FRONT | 180MM 6 BOLT |
| ROTOR REAR | 160MM 6 BOLT |
| CRANKSET AND FRONT CHAINRINGS | 42T- ED STEEL, W/DOUBLE RESIN CG 170MM |
| BOTTOM BRACKET | SEALED BSA CARTRIDGE |
| CHAIN | KMC 7 SPEED |
| PEDALS | 9/16 RESIN PLATFORM |
| REAR GEARS | 7 SPEED |
| CASSETTE DESCRIPTION | SHIMANO TZ500 14-28T |
| HANDLEBAR | W:640MM, R:30MM, BACKSWEEP:38D,BARBORE:31.8MM |
| HANDLEBAR STEM | A HEAD, EXT:90MM H:41MM,BAR BORE:31.8MM,ED BOLT,ADJUSTBALE:10-50DEGREE |
| HEADSET | A HEAD,28.6MM,44*44MM,W/15MM RESIN BLACK CONE |
| GRIPS / BAR TAPE | JT-G107 L/R:130MM, CLOSED END |
| SEAT POST | 30.9*350MM, W/ALLOY HEAD |
| SADDLE | JT5723 - 182MM BLACK COMFORT |
| FRONT AND REAR HUBS | F: SF-A262F 36H QR 6 BOLT LBB / R: HUB MOTOR NUTTED |
| FRONT AND REAR RIMS | RD-H20 27.5"*36H*14G, DOUBLE WALL, F/V W/EYELETS |
| FRONT AND REAR TYRES | P1440 CITY TREAD - 27.5" X 1.95" |
| WHEEL SIZE | 27.5" (650B) |
| FRONT AND REAR LIGHTS | FRONT & REAR 6V LED |
| FENDER | 65MM STEEL PAINTED |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | KICKSTAND, 42V 2A CHARGER (3 PIN FOR 36V BATTERY), INTEGRATED SINGLE STAY PANNIER RACK (NOT FOR CHILD SEAT USE) |
| DRIVE UNIT LOCATION | REAR WHEEL |
| DRIVE UNIT DESCRIPTION | CZJB 90T PLANETARY DRIVE |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 40 |
| BATTERY DESCRIPTION | REMOVABLE 36V EEL MINI |
| BATTERY SIZE (WATT-HOURS) | 374 |
| CHARGE TIME (HOURS) | 5 |
| DISPLAY | KD716 + K5 |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 50 |
| IP RATING | IP54 |
| WEIGHT LIMIT | 100KG |
