| FRAME MATERIAL | ALLOY |
| FRAME DESCRIPTION | STEP THROUGH ALLOY 6061 POD BATTERY |
| FRAME STYLE | STEP-THROUGH |
| FORK MATERIAL | STEEL |
| FORK BRAND | PEDAL |
| FORK DESCRIPTION | RIGID STEEL |
| FRONT TRAVEL | |
| DERAILLEUR FRONT | 1X |
| DERAILLEUR REAR | SHIMANO TOURNEY 7 SPEED |
| GROUPSET | SHIMANO MIXED |
| SHIFTERS | LTWOO TRIGGER 7 SPEED |
| BRAKES | TEKTRO HD-M275 |
| BRAKE TYPE | HYDRAULIC DISC BRAKE |
| ROTOR FRONT | 160MM 6 BOLT |
| ROTOR REAR | 160MM 6 BOLT |
| CRANKSET AND FRONT CHAINRINGS | 48T - ED STEEL W/DOUBLE CHAINRING, 170MM ALLOY ARM |
| BOTTOM BRACKET | SEALED BSA CARTRIDGE 165MM |
| CHAIN | LIXING P50 7 SPEED |
| PEDALS | PLATFORM 9/16" W/REFLECTOR |
| REAR GEARS | 7 SPEED |
| CASSETTE DESCRIPTION | SHIMANO TZ500 14-28T |
| HANDLEBAR | DNF-A832 600MM STEEL BMX STYLE |
| HANDLEBAR STEM | DNF-M710 ALLOY 45.6MM 25.4MM |
| HEADSET | INTEGRATED 44MM |
| GRIPS / BAR TAPE | XL G78 125MM ERGO RUBBER |
| SEAT POST | 300MM 27.2MM ALLOY SINGLE BOLT |
| SADDLE | QF2045 270X170MM BLACK ERGO FOAM |
| FRONT AND REAR HUBS | F: ALLOY LBB W/NUTTED 6 BOLT (SF-HB30F, 3/8*135*175) / R: ELECTRIC GEARED HUB MOTOR NUTTED |
| FRONT AND REAR RIMS | ALLOY SINGLE WALL 20" 36H 13G 80MM WIDE |
| FRONT AND REAR TYRES | WANDA P1272 20X4" KNOBBLY RUBBER |
| WHEEL SIZE | 20" |
| FRONT AND REAR LIGHTS | FRONT & REAR 6V LED |
| FENDER | 100MM PVC BLACK |
| ACCESSORIES (KICKSTAND, PANNIER RACK, CHARGER) | KICKSTAND + 42V 2A CHARGER (3 PIN FOR 36V BATTERY), REAR PILLION PASSENGER KIT (INCLUDING FOAM BENCH, X2 GRAB HANDLES, SKIRT GUARDS, FOLDING FOOT RESTS) |
| DRIVE UNIT LOCATION | REAR WHEEL |
| DRIVE UNIT DESCRIPTION | CZJB 110-C PLANETARY DRIVE |
| MOTOR POWER (WATTS) | 250 |
| MOTOR TORQUE (NM) | 40 |
| BATTERY DESCRIPTION | REMOVABLE POD BATTERY 36V |
| BATTERY SIZE (WATT-HOURS) | 540 |
| CHARGE TIME (HOURS) | 7 |
| DISPLAY | KD-58C |
| ASSIST MODES | 5 MODES |
| RANGE (KMS) | 50 |
| IP RATING | IP54 |
| WEIGHT LIMIT | 100KG |
