Geometeries
Size | XL | XS | SM | MD | LG |
---|---|---|---|---|---|
Stack | 593 | 529 | 542 | 557 | 571 |
Reach | 409 | 384 | 390 | 395 | 400 |
Top Tube Length | 590 | 536 | 545 | 560 | 575 |
Seat Tube Length | 590 | 500 | 520 | 540 | 560 |
Seat Tube Angle | 73.0 | 74.0 | 74.0 | 73.5 | 73.0 |
Fork Length | 385 | 385 | 385 | 385 | 385 |
Head Tube Length | 176 | 112 | 128 | 140 | 155 |
Head Tube Angle | 74.0 | 72.0 | 72.5 | 73.5 | 73.5 |
Bottom Brack Drop | 66 | 70 | 66 | 66 | 66 |
Chainstay Length | 408 | 408 | 408 | 408 | 408 |
Standover Height | 853 | 771 | 792 | 810 | 826 |
