Geometeries
Size | XXXS | XXS | XS | SM | MD | LG | XL |
---|---|---|---|---|---|---|---|
Stack | 512 | 517 | 529 | 542 | 557 | 571 | 593 |
Reach | 373 | 377 | 383 | 390 | 395 | 400 | 409 |
Top Tube Length | 505 | 520 | 535 | 545 | 560 | 575 | 590 |
Seat Tube Length | 400 | 435 | 458 | 481 | 501 | 521 | 550 |
Seat Tube Angle | 75.5 | 74.5 | 74.0 | 74.0 | 73.5 | 73.0 | 73.0 |
Fork Length | 385 | 385 | 385 | 385 | 385 | 385 | 385 |
Head Tube Length | 100 | 105 | 112 | 128 | 140 | 155 | 176 |
Head Tube Angle | 70.5 | 70.5 | 72.0 | 72.5 | 73.5 | 73.5 | 74.0 |
Bottom Brack Drop | 70 | 70 | 70 | 66 | 66 | 66 | 66 |
Chainstay Length | 408 | 408 | 408 | 408 | 408 | 408 | 408 |
Standover Height | 700 | 721 | 745 | 765 | 782 | 800 | 823 |
