Geometeries
Size | LG | XL | XXS | XS | SM | MD |
---|---|---|---|---|---|---|
Stack | 571 | 593 | 517 | 529 | 542 | 557 |
Reach | 400 | 409 | 377 | 383 | 390 | 395 |
Top Tube Length | 575 | 590 | 520 | 535 | 545 | 560 |
Seat Tube Length | 521 | 550 | 435 | 458 | 481 | 501 |
Seat Tube Angle | 73.0 | 73.0 | 74.5 | 74.0 | 74.0 | 73.5 |
Fork Length | 385 | 385 | 385 | 385 | 385 | 385 |
Head Tube Length | 155 | 176 | 105 | 112 | 128 | 140 |
Head Tube Angle | 73.5 | 74.0 | 70.5 | 72.0 | 72.5 | 73.5 |
Bottom Brack Drop | 66 | 66 | 70 | 70 | 66 | 66 |
Chainstay Length | 408 | 408 | 408 | 408 | 408 | 408 |
Standover Height | 800 | 823 | 721 | 745 | 765 | 782 |
